JUMBO Filtertrolley 2.0 ASD – mobile dust extractor

Blue-grey unit with pull-out handle for dust extraction

Product details

Application fields

Flexible extraction for shifting workplaces and small to moderate dust discharge
Grinding, engraving, burnishing, cleaning, abrading, decanting, etc.

Features

Uniquely designed mobile dust extraction device
High extraction performance, stepless adjustment
Extremely quiet operation
Easy filter handling, access via suction plate
ABS Material (impact-resistant, chemical-resistant, corrosion-resistant)
Installation of extraction arms (Ø 50/75) and collection elements typical for your application
Utilization of particle filter elements (HEPA - H13/H14)

Technical specifications

Device version	JUMBO Filtertrolley 2.0 ASD
Max. flow rate in m³/h	190
Max. flow rate in cfm	112
Max. vacuum in Pa	3200
Max. vacuum in inch wc	12.9
Nominal capacity in m³/h@Pa	80 @ 1900
Nominal capacity in cfm@inch wc	47 @ 7.6
Dimensions in mm (WxDxH)	450x340x530
Dimensions in inch (WxDxH)	17.8x13.4x20.8
Weight in kg	36
Weight in lbs	79
Noise level in dB	49
Connection variants – diameter in mm	1 X 50 / option: 1 X 75
Connection variants – diameter in inch	1 X 1.97 / option: 1 X 2.95

System benefits

Quiet operation
ULT’s extraction and filtration systems are especially quiet. This is appreciated by numerous clients worldwide. This means your employees won’t be bothered by unnecessary noise.
High flexibility
Many of the ULT fume extraction systems can be utilized flexibly. For example, you can choose between mobile or stationary systems, device integrations or special ventilation solutions. If necessary, the ideal application is configured by ULT experts on-site.
Easy servicing
ULT’s extraction and filtration systems are designed so that they can be put into operation without problems and easily used. Should there be any questions, our service technicians would be happy to assist you at any time.
Low energy requirements
ULT’s extraction systems reduce the operation and maintenance costs based on your optimal filtration plan. In addition, the system is designed so that the required energy consumption is kept very low.
R&D basis
Research and Development (R&D) has a very high priority at ULT. Several projects with prestigious partners and institutes have produced new approaches to ventilation systems that often become series products or are adapted quickly and easily to customer-specific projects.
Optimal filter technology
Using the most sensible filtration technology ensures a long filter service life and, consequently, reduces the costs of maintenance and spare parts. ULT always offers you the optimal solution for your special contaminant technology to achieve the best filtration possible.
